Cyclone Water Curtain Spray Booth | Wet Type Paint Overspray Collection System for Industrial Painting Applications
The Cyclone Water Curtain Spray Booth is a high-efficiency wet-type paint mist collection system designed for industrial painting, coating, spraying, and finishing operations. Utilizing a combination of water curtain filtration, cyclone separation, and multi-stage mist removal technology, the equipment effectively captures paint overspray, dust particles, VOC-laden droplets, and airborne contaminants before exhaust discharge.
$5000
Function: Paint overspray collection and air purification
Technology: Water curtain + cyclone separation
Application: Industrial painting and coating
Structure: Integrated modular design
Housing Material: Galvanized steel / Stainless steel
Frame Material: Heavy-duty steel construction
Water Curtain System: Integrated high-efficiency curtain
Cyclone Separator: Multi-stage mist separation
Paint Mist Removal Efficiency: Up to 95%-99%
Airflow Capacity: 5,000-100,000 m³/h
Product Details
Product Details
Cyclone Water Curtain Spray Booth
The Cyclone Water Curtain Spray Booth is an advanced wet-type air purification and paint overspray collection system designed to remove paint mist, coating particles, and airborne contaminants generated during spraying operations. By combining water curtain filtration with cyclone separation technology, the system achieves excellent purification performance while maintaining low operating costs.
Technical Specifications & Features
| No. | Attribute | Description |
|---|---|---|
| 1 | Product Type | Cyclone Water Curtain Spray Booth |
| 2 | Function | Paint overspray collection and air purification |
| 3 | Technology | Water curtain + cyclone separation |
| 4 | Application | Industrial painting and coating |
| 5 | Structure | Integrated modular design |
| 6 | Housing Material | Galvanized steel / Stainless steel |
| 7 | Frame Material | Heavy-duty steel construction |
| 8 | Corrosion Resistance | Excellent |
| 9 | Water Curtain System | Integrated high-efficiency curtain |
| 10 | Cyclone Separator | Multi-stage mist separation |
| 11 | Paint Mist Removal Efficiency | Up to 95%-99% |
| 12 | Dust Collection Efficiency | High efficiency |
| 13 | Airflow Capacity | 5,000-100,000 m³/h |
| 14 | Water Tank | Integrated recirculation tank |
| 15 | Water Pump | Industrial circulation pump |
| 16 | Water Recycling | Closed-loop water circulation |
| 17 | Filtration Stage | Multi-stage purification |
| 18 | VOC Reduction | Optional treatment module |
| 19 | Exhaust Configuration | Customizable |
| 20 | Control System | PLC automatic control |
| 21 | Operation Mode | Automatic or manual |
| 22 | Power Supply | 380V/50Hz or customized |
| 23 | Energy Consumption | Low operating cost |
| 24 | Noise Level | Low-noise operation |
| 25 | Airflow Design | Optimized airflow management |
| 26 | Safety System | Industrial safety protection |
| 27 | Explosion-Proof Option | Available |
| 28 | Environmental Compliance | Meets emission standards |
| 29 | Water Consumption | Low water usage design |
| 30 | Maintenance | Easy cleaning and servicing |
| 31 | Installation | Floor-mounted |
| 32 | Transport | Container shipment available |
| 33 | Automation | High automation level |
| 34 | Remote Monitoring | Optional |
| 35 | Paint Types | Water-based and solvent-based coatings |
| 36 | Application Method | Manual or robotic spraying |
| 37 | OEM Service | Available |
| 38 | ODM Service | Available |
| 39 | Certification | CE / ISO Optional |
| 40 | Service Life | 10-20 Years |
| 41 | Furniture Industry | Suitable |
| 42 | Automotive Industry | Suitable |
| 43 | Metal Fabrication | Suitable |
| 44 | Machinery Manufacturing | Suitable |
| 45 | Customization | Size and airflow customizable |
